Wildeck VRC Wheel Block Assembly 5-1/4" or 5-7/16"

This wheel block assembly is designed for use on compatible Wildeck Vertical Reciprocating Conveyor (VRC) lift carriages. Each assembly uses a phenolic wheel and is available in upper or lower configurations to match its mounting position on the carriage.

Select the required wheel diameter, block configuration, and handing when ordering. Available combinations include 5-1/4" and 5-7/16" diameter wheels, upper and lower wheel blocks, and left-hand (LH) or right-hand (RH) installations.

Wildeck VRCs may use wheel blocks with different wheel materials, diameters, mounting positions, and handing. If any of these details are unknown, provide the lift serial number, VRC SO number, or Job Number with your order so the correct configuration can be identified for the specific lift.

• Application: Wildeck Vertical Reciprocating Conveyor (VRC) lifts
• Component type: Wheel block assembly
• Wheel material: Phenolic
• Wheel diameter options: 5-1/4" or 5-7/16"
• Block position options: Upper or lower
• Handing options: Left-hand (LH) or right-hand (RH)
• Configuration combinations: 8 available variants
• Installation location: VRC carriage wheel assembly
• Assembly type: Complete wheel block configuration

Wheel block assemblies are load-bearing mechanical components and should be correctly matched to the original lift configuration. Installation, inspection, and replacement should be performed by qualified personnel in accordance with applicable equipment procedures and safety requirements.
