Wheelchair Lift Motor

Compatibility:
This 90 VDC motor is commonly found in many wheelchair lifts.
This motor does NOT feature a bolt pattern in the face of the motor. It can only be secured to the lift using the bolt plate under motor.

Product Overview:
This 90VDC Motor is a high-quality, permanent magnet DC motor designed for reliable performance in various lift systems. The 110ZYT145 features robust construction and efficient operation make it suitable for demanding applications.

Key Specifications:

• Series: 110ZYT145/A1
• Voltage: 90 VDC
• Power Output: 245W
• Speed: 1800 RPM
• Motor Type: Brushed DC Motor
• Mounting: Standard IEC 63B14 flange
• Shaft Diameter: 16mm (5/8") keyed shaft

Features:

• High Torque: Provides reliable power for lift operations.
• Durable Construction: Ensures longevity and consistent performance.
• Efficient Operation: Designed for optimal energy use.

Important Information:

• Compatibility: Suitable for use in variety of platform lift systems.
• Installation: Professional installation is recommended to ensure safety and proper functionality.

For more detailed information or to confirm specific dimensions, please refer to the manufacturer's documentation or consult with a professional installer.
