Waupaca Gate Operator 3-Belt Stepped Idler Pulley Sheave

Legacy part number M-001765 identifies this stepped idler pulley used on the motor side of the Waupaca AutoGate Gate Operator. It works with the motor-mounted 2-belt drive sheave and two Clear-Go 85 belts to receive power from the operator motor.

The stepped design provides separate belt-running surfaces within the AutoGate drive system. The two Clear-Go belts drive the idler from the motor side, while the idler in turn drives the longer red belt used farther through the operator's drive arrangement.

• Included: Pulley Only. Belts sold separately.
• Application: Waupaca AutoGate Gate Operator
• Component type: Stepped idler pulley / sheave
• Mounting location: Motor side of operator
• Groove configuration: 3-belt stepped design
• Input drive: Two Clear-Go 85 belts
• Output drive: Long red operator belt
• Function: Transfers motor drive to the longer belt through the idler assembly

Gate operator drive components should be installed and inspected by qualified personnel using appropriate installation practices and applicable equipment requirements. Correct pulley alignment and belt installation are important for dependable operation and proper performance of the drive assembly.
