Trus-T-Lift RAM 750 VPL Timing Belt Replacement

This synchronous drive belt is used in select Trus-T-Lift RAM 750 vertical platform lift applications where precise, slip-resistant motion transfer is required.

Manufactured to a 5mm pitch timing belt profile, it provides consistent engagement with matching pulleys to help maintain smooth lift operation. This replacement belt is an ideal solution when replacing a broken/worn belt or as regular, preventative maintenance. Constructed with a durable elastomer body and reinforced tensile cords, the belt is designed for long service life in demanding accessibility lift environments.

• Compatible with select Trus-T-Lift RAM 750 vertical platform lifts
• Synchronous timing belt design
• Pitch: 5 mm
• Belt length: 700 mm (27.56 in.)
• Belt width: 15 mm (0.59 in.)
• Tooth count: 140
• Tooth profile: Curved HTD profile
• Reinforcement: Fiberglass tensile cords
• Belt material: Chloroprene/Neoprene compound
• Nylon tooth facing
• Oil- and heat-resistant construction
• Single-sided toothed design

For dependable lift performance and long-term reliability, replacement drive components should always be installed and inspected by qualified personnel in accordance with applicable equipment maintenance procedures. Proper installation and routine system inspection help ensure continued safe operation of the lift.
