National Wheel-o-Vator
Round Pushbutton Block - NWOV, Dover, and Others
Round Pushbutton Block - NWOV, Dover, and Others
🔄 Backorder Available
This item is available for backorder. Estimated lead time is 1 to 2 weeks. We’ll send an update once your order is confirmed and provide tracking when it ships.
SKU: PB.NWOV.SPST
Condition: New
Couldn't load pickup availability
Compatible with a Variety of Lift Brands Including National Wheel-O-Vator (NWOV) and Dover
This versatile momentary push button is a common component in many elevators, wheelchair lifts, and stairlifts. It is designed for multifunctional use, serving reliably as a limit switch, Up/Down button, gate switch, and more.
Specifications:
- Circuit Configuration: Single-Pole Single-Throw (SPST) Normally Open (NO)
- Contact Ratings:
- 15A at 125V AC
- 10A at 250V AC
- 1/3 HP at 125–250V AC
- Actuator Type: Round metal button
- Mounting Type: Panel mount with threaded bushing
- Terminal Type: Brass screw terminals
- Button Extension: 0.250 inches (6.35 mm)
- Bushing Length: 0.343 inches (8.71 mm)
- Operating Force: Approximately 0.9 lbs
Known for its reliability and adaptability, this pushbutton is most commonly found in National Wheel-O-Vator (NWOV) and Dover equipment but is compatible with a wide range of accessibility and vertical transportation systems. Its durable construction and flexible application make it a go-to replacement part for technicians and lift owners alike.
