Residential Light Ray Assembly - Symmetry and Others

Compatible with Symmetry Residential Elevators and Many Other Systems Meeting Specifications

24VDC Super Slim Door Detector

This pair of edge detectors is a high-performance safety device designed to enhance passenger protection by preventing elevator doors from closing when an obstruction is detected. While commonly found in Symmetry Residential Elevators, its versatile design allows for integration into various elevator systems that meet its specifications.

Key Features:

• Ultra-Slim Profile: Measuring just 6.6mm in thickness, the super slim design facilitates easy installation in tight spaces without compromising functionality.
• Comprehensive Detection: Equipped with 94 non-parallel infrared beams across 32 diode pairs, it offers a detection height ranging from 20mm to 1841mm, ensuring thorough coverage.
• Rapid Response: With a swift response time of 65ms, the detector promptly identifies obstructions, enhancing passenger safety.
• Robust Performance: Engineered to withstand ambient light conditions up to 100,000 Lux, ensuring reliable operation even in brightly lit environments.
• Flexible Installation: Features two 3,500mm long flexible connection cables, providing ample length for various installation configurations.
• Contents: 2 x Light Curtains, 2 x True Travelling Cables, 1 x 24VDC Transformer, Installation Accessories, and Installation Manual


Specifications:

• Dimensions: 6.6mm (thickness) x 30mm (width) x 2000mm (height)
• Number of Infrared Beams: 94 non-parallel
• Number of Diodes: 32 pairs
• Scan Mode: 3-way
• Response Time: 65ms
• Diode Spacing: 59mm
• Operating Range: 0 – 3000mm (up to 4000mm as required)
• Detection Height: 20mm – 1841mm
• Infrared Pulses Ratio: 1:2
• Maximum Ambient Light: ≥100,000 Lux
• Linear Tolerance: ±15mm vertical, ±4mm horizontal
• Connection Cables: 2 x 3,500mm flexible cables
• System Indicators: Normal, Interrupted, Faulty

Enhance the safety and reliability of your elevator system with these light curtains. Their advanced features and slim design make them an ideal choice for modern elevator installations.

➡️ Order now to ensure optimal safety and performance for your elevator system!

Note: Ensure compatibility with your specific elevator model and system requirements before installation.
