Replacement Emergency Light Board for Dover & ThyssenKrupp
Replacement Emergency Light Board for Dover & ThyssenKrupp
🔄 Backorder Available
This item is available for backorder. Estimated lead time is 8 to 14 business days. We’ll send an update once your order is confirmed and provide tracking when it ships.
SKU: PCB.DV.EML
Condition: New
Couldn't load pickup availability
This Replacement Emergency Light PCB is designed for Dover and ThyssenKrupp elevator applications, offering reliable illumination during power loss. Equipped with two bright white LEDs and an optional 6V 5Ah battery, it delivers consistent light output for hours, ensuring safety and visibility inside the elevator car.
Directly replaces part numbers 6300GD1, 110938, 110941, 118412, 149355, 9818420, and 9839720.
Features:
- Compatible with many Dover & ThyssenKrupp elevator models
- Direct replacement for multiple OEM part numbers
- Two high-output white LEDs for bright, even lighting
- Optional 6V 5Ah battery for up to 6 hours of emergency illumination
- Solid-state automatic constant current charger (100mA)
- Red LED indicator for AC power monitoring
- Mounts with four screws to existing Dover bracket
- Lightweight, durable construction
Technical Specifications:
| Specification | Details |
|---|---|
| Light Source | 2 white LEDs |
| Input Voltage | 120VAC, 50–60 Hz |
| Charging Current | 12mA @ 120V input, 100mA @ battery |
| Lighting Current | 400mA (from battery) |
| Battery (optional) | 6V 5Ah |
| Emergency Duration | 24 lux (0–4 hrs), 22 lux after 6 hrs |
| Charger | Solid-state automatic constant current |
| Monitoring | Red LED AC supply indicator |
| Diffuser / Alarm Bell / Button | Not supplied |
| Mounting | 4-screw to existing Dover bracket |
| Weight | 0.75 lb |
| Dimensions | 5.5″ x 3.25″ x 1.5″ |
Measurements taken with light mounted 6 ft above floor in car operator panel, readings at 28″ above floor, 1 ft in front of pushbutton panel using a Cooke cal-LIGHT 400 light meter.
Package Includes:
- MES788M Emergency Light
- Mounting hardware (4 screws)
(Battery, diffuser, alarm bell, and alarm button sold separately)
