REI Elevator Emergency Stop - Pit Switch - Car Top E-Stop Switch

Reliable replacement emergency stop switch assembly designed for elevator pit and car top applications commonly found among Residential Elevators Inc models.

Stop switch assembly with pull-to-reset actuator replaces common pit and car top switches on residential and commercial elevators. Visual status indicator shows a clear RED stop position and permits a simple green run indication when reset. Rugged chassis mount construction with screw terminals supports standard field wiring, and durable housing with IP65 environmental protection resists dust and moisture in machine room and hoistway environments. Rated to handle up to 16 A at 600 V AC with a single normally-closed safety contact for reliable emergency circuit interruption, this switch matches the form, fit, and function of select REI and similar elevator emergency stop components.

Key Specifications:
• Contact Configuration: Single Pole Single Throw – Normally Closed safety contact
• Electrical Rating: Up to 16 A at 600 VAC
• Actuator Type: Pull-to-reset emergency stop button with visual indicator
• Mounting: Chassis / box mount with vertical cable entry
• Termination: Screw terminals for robust field wiring
• Environmental Protection: IP65 – dust tight and water resistant
• Operating Temp: –25 °C to 70 °C typical

Professional quality emergency stop replacement suitable for elevator service technicians and qualified installers seeking a dependable pit or car top safety switch that fits a wide range of applications.

Installed and operated by qualified elevator service personnel only; follow all applicable safety codes and requirements for emergency stop and safety circuit devices.
