RAE Corporation Motor for Cemco Gate Operators
RAE Corporation Motor for Cemco Gate Operators
🔄 Backorder Available
This item is available for backorder. Estimated lead time is 8 to 14 business days. We’ll send an update once your order is confirmed and provide tracking when it ships.
SKU: CMC.MTR.130
Condition: New
Couldn't load pickup availability
Compatible with various CEMCO residential elevators utilizing 130VDC gate and door operator motors.
Direct replacement motor for CM‑2523, designed for smooth, consistent operation in residential elevator gate and door operator systems.
This RAE Corporation motor is a standard replacement for aging or worn motors found in the gate operators and door operator systems of many CEMCO residential elevators. It supports reliable operation for both the door opener and door closer operation, maintaining proper synchronization and performance.
Specifications
-
- Voltage: 130 VDC
- Current: 0.64 Amps
- Speed: 2876 RPM
- Torque: 30 in-oz
- Insulation Class: F
- Enclosure: TENV (Totally Enclosed Non-Ventilated)
- Frame: 1.4
- Mounting: Flange
- Shaft Diameter: 0.25 inches
Ensure alignment with original mounting and electrical specs before installation.
