Porch-Lift Emergency Stop Button - Small Head

Compatible with: Porch-lift units and potentially other applications.

Product Overview: This compact emergency stop push button is designed for safety in various industrial and commercial applications. Its 16mm diameter makes it ideal for installations where space is limited.

Key Features:

• Design: Red circular head with a 30mm pushbutton.
• Operation: Trigger latching mechanism with turn-to-release functionality.
• Contacts: 1 Normally Open (NO) and 2 Normally Closed (NC) slow break contacts.
  Some PLS units do not require the 2nd NC contact. In this case, it can be removed or ignored.

• Connection Type: Faston connections for quick and secure wiring.
• Compliance: Meets IEC, UL, CSA, and CCC standards.

Specifications:

• Mounting Diameter: 16mm
• Head Diameter: 30mm
• Contact Configuration: 1 NO + 2 NC
• Connection: Faston terminals
• Standards Compliance: IEC, UL, CSA, CCC

Applications: While commonly found in porch-lift units, this switch can also be a suitable replacement for:

• Car Top Switches
• Pit Switches
• Other brands that require similar specifications.

Note: Ensure compatibility with your specific equipment before installation. Professional installation is recommended to maintain safety and compliance with relevant standards.
