Phase Sequence Monitoring Relay - Inclinator
Phase Sequence Monitoring Relay - Inclinator
🔄 Backorder Available
This item is available for backorder. Estimated lead time is 1 to 2 weeks. We’ll send an update once your order is confirmed and provide tracking when it ships.
SKU: RLY.PMR.INC
Condition: New
Couldn't load pickup availability
Compatible with: Many Inclinator models
Product Description:
Ensure the reliable operation of your lift system with this high-quality phase sequence monitoring relay. Designed to detect incorrect phase sequences and phase failures, it safeguards your equipment from potential damage due to power supply issues. This relay is an essential component for maintaining the safety and efficiency of your lift system.
Specifications:
- Function: Phase failure detection and phase sequence monitoring
- Output: 1 SPDT (Single Pole Double Throw) contact rated at 250V AC / 4A
- Rated Control Supply Voltage: 208 to 440 V AC (L-L)
- Measuring Range: 208 to 440 V AC (L-L)
- Time Range: 500 ms start-up delay; 500 ms tripping delay
- Operating Temperature: -20 to 60°C
- Mounting: DIN rail
- Terminal Type: Screw terminals
- Dimensions (W x H x D): 22.5 mm x 78 mm x 78.5 mm
- Net Weight: 0.068 kg
- IP Rating: IP20
By integrating this phase sequence monitoring relay into your lift system, you can effectively monitor and protect against phase-related issues, ensuring continuous and safe operation.
