ON/OFF Rocker Switch for Acorn & Brooks Stairlift Carriage / Chassis

Replacement ON/OFF power toggle for Acorn / Brooks stairlifts – matches OEM #814‑000210, rated for 16 A AC / 250 V, panel mount, SPST.

This rocker switch provides reliable power control for the carriage (chassis) of Acorn and Brooks stairlifts (SWL), including SL120 and SL130 models. It is a direct fit replacement for OEM part #814‑000210. The switch is single-pole, single-throw (SPST) non‑illuminated rocker type, panel mounted, with quick‑connect terminals—making installation straightforward.

Made with high‑inrush tolerant contacts and built to withstand substantial load cycling, the switch is suitable for AC use in stairlift circuits. The actuator is a soft‑line black rocker with a clear ON/OFF marking. Designed for panel thicknesses within standard stairlift chassis assemblies.

Specifications

• Switch type: ON/OFF (SPST) rocker switch
• Rated contact current: 16 A AC
• Voltage rating AC: 250 V AC
• DC rating: 28 V DC as per vendor spec
• Panel cut‑out dimensions: approx. 30.10 mm × 11.10 mm (rectangular)
• Panel thickness supported: 0.75 mm to ~3.0 mm
• Termination style: Quick‑connect terminals (≈ 6.3 mm)
• Material: shell/rocker: nylon 6.6; current‑carrying parts copper alloy with silver‑plated contacts
• Inrush current (EN61058‑1): approx 150 A
• Insulation resistance: > 20 MΩ
• Contact resistance (new state, 12 V DC, 1 A): < 100 mΩ
• Operating ambient temperature rating up to ~125 °C

This switch replacement has been engineered to match the performance and fit of the original OEM component in Acorn / Brooks stairlifts. For safety and proper function, installation should be performed by qualified personnel, ensuring secure mounting and wiring according to relevant regulations.
