NWOV Elevator 800VA Emergency Lowering Battery Backup UPS

UPS with 800VA output, exceeding obsolete 700VA recommendations for National Wheel‑O‑Vator Destiny and Evolution models. Replaces #L-1040.

High‑capacity uninterruptible power supply designed to provide reliable emergency backup for vertical platform lifts and other mobility systems previously using 700VA units.
This UPS delivers 800VA/480W of output power to support critical functions during power interruptions, offering enhanced reserve capacity compared to legacy backups.
Built with robust surge protection and battery management features, it ensures stable power delivery to drive controllers and essential circuitry.

Note the physical size of this UPS. Verify available space before installation and plan relocation if access or clearance is limited.

• Capacity: 800VA / 475W
• Input Voltage: 230V nominal
• Output Voltage: 230V nominal
• Outlets: 4 x IEC-320-C13
• Battery Type: Valve-regulated, lead-acid (VRLA), user-replaceable
• Communications Interface: USB port
• Topology: Line-interactive
• Dimensions: 10.8 x 5.2 x 7.5 in (HxWxD)
• Form Factor: Tower
• Features: Automatic voltage regulation, cold-start capability, overload protection

This UPS is intended for use as a replacement backup power source in compatible elevator and lift applications. Ensure proper sizing and clearances for safe placement, and have installation performed by qualified personnel familiar with mobility systems and electrical safety standards.
