Garaventa Genesis Nidec Valeo 24V Platform Wheelchair Lift Motor

Compatible with many Garaventa and Genesis vertical platform lifts, including the GVL-SW-96 model and select Xpress II Xpress 2 models.

Standard Nidec-Valeo 24V gearbox motor used in select Garaventa lift systems; features right-hand worm gear configuration and 2Nm rated torque.

• Designed for 24V DC systems with right-hand gear orientation
• Rated torque: 2 Nm; stall torque: 14 Nm
• Rated speed under load: 44 rpm
• No-load speed: approx. 52–54 rpm
• Gear ratio: approx. 85:1 worm drive
• Shaft: 8 mm diameter, ~23.2 mm length, 3.5 mm bore
• Mounting bolt circle: 84 mm; hole spacing: 62–62.5 mm
• Power rating: 36 W
• Self-locking design (~0.5 Nm) with worm gear transmission
• Housing: zinc die-cast with ball and cup bearing supports

This compact 24-volt DC gear motor is commonly found in Garaventa/Genesis VPL systems, though the exact application may vary. Its distinct housing and shaft layout help installers visually confirm compatibility.
