Micron Power Supply for Symmetry Elevator Controller

24 V DC, 60 W DIN‑rail power supply ideal for residential elevator controllers; replaces EEP‑C017‑E and discontinued Micron MDP60‑24A‑1C.

This DIN‑rail mounted switching power supply converts universal AC input (85–264 VAC) to a stable 24 V DC output and is exactly what select controllers for Bella/Symmetry residential elevators require.
It is commonly used as the replacement for older or discontinued units such as the original power module EEP‑C017‑E or the discontinued transformer MDP60‑24A‑1C.
The slim-line, compact form factor makes it easy to install inside elevator control panels, and the unit is built to meet industrial safety and reliability standards. With protections against overload, overvoltage, short-circuit, and inrush conditions, it ensures safe, stable power for elevator controller electronics.

Specifications:

• Input Voltage: 85–264 VAC, 50/60 Hz
• Output Voltage: 24 V DC (adjustable range 21.6–26.4 V)
• Output Current: 2.5 A
• Output Power: 60 W
• Ripple & Noise: 150 mV p‑p
• Protections: Short‑circuit, overload, overvoltage, inrush current handling
• Operating Temperature: –20 °C to +60 °C (–4 °F to +140 °F)
• Mounting: DIN‑rail rail (slim‑line)
• Isolation: 3000 VAC between input and output
• Certifications: UL/cUL/CE; UL 1310 Class 2 rated
• Connector Wire Size: AWG 26–12

This power supply is a reliable, drop-in replacement for older or discontinued elevator controller power modules. When installed by qualified personnel, it delivers stable 24 V DC power for elevator systems while offering modern protections and compliance. Always ensure that installation is performed in accordance with best practices and applicable codes for safety and performance.
