Magnetic Reed Switch - Garaventa / Genesis
Magnetic Reed Switch - Garaventa / Genesis
Regular price
$29.92 USD
Regular price
$40.00 USD
Sale price
$29.92 USD
Unit price
/
per
Shipping calculated at checkout.
No reviews
🔄 Backorder Available
This item is available for backorder. Estimated lead time is 8 to 14 business days. We’ll send an update once your order is confirmed and provide tracking when it ships.
SKU: MS.GV.34
Condition: New
Couldn't load pickup availability
Compatible with many Garaventa & Genesis VPLs
This Amseco Mag Switch can be found in many wheelchair lifts, including a variety of Garaventa / Genesis lifts, acting as the door close sensor of many lift gates.
Technical Specifications
- Color: Ivory
- UL Listed
- Self-locking
- Contact: 22AWG - 24" Lead
- Contact Rating: 10VA
- Contact Type: Form A N.O.
- Max. Carry Current: 1.0 Amp
- Max. Switching Current: 0.3 Amp
- Breakdown Voltage: 200VDC
- Operating Gap: 3/4"
- Mounting Method: Press fit
- Operating Temperature Range: 32F to 120F (0C to 49C)
