Lovato Type BG09 AC Contactor Block for Harmar Summit Stair Lift

The Lovato BG09 24-volt AC contactor is used in select Harmar Summit stair lifts and replaces legacy part number 16002. While technically a contactor rather than a relay, this component is commonly referred to as a relay or contact relay within the stair lift industry, making it easier for technicians and owners to identify the correct replacement part.

Designed for reliable switching performance, this compact power contactor features a 24VAC coil, three power poles, and an integrated normally closed auxiliary contact. Its durable construction and compact footprint make it well-suited for accessibility equipment applications where dependable electrical control is required. Compatible with select Harmar Summit stair lift models that originally utilized the legacy 16002 contactor relay.

• 24VAC coil voltage
• BG09 series power contactor
• Three-pole configuration
• Integrated 1 normally closed (NC) auxiliary contact
• 9A AC-3 operational current rating
• 20A AC-1 thermal current rating
• DIN rail or screw mounting
• Approximate dimensions: 58mm x 57mm x 44mm
• Operating temperature range: -50°C to +70°C
• Suitable for select Harmar Summit stair lift applications replacing legacy part 16002

For safety and long-term reliability, all replacement electrical components should be installed and inspected by qualified personnel familiar with accessibility equipment. Proper installation and verification of compatibility help ensure continued performance of the stair lift system.
