Long-arm Safety Slack Switch w/ Reset Button - Lev and Porch-lift
Long-arm Safety Slack Switch w/ Reset Button - Lev and Porch-lift
🔄 Backorder Available
This item is available for backorder. Estimated lead time is 1 to 2 weeks. We’ll send an update once your order is confirmed and provide tracking when it ships.
SKU: SS.PLS.LEV
Condition: New
Couldn't load pickup availability
This premium large basic snap-action switch is engineered for high-reliability applications requiring precise actuation and durability. It is commonly utilized as a manually-reset slack switch in hydraulic Porch-lifts and many TKA Lev elevators, serving as a critical safety component to detect slack conditions in lifting chains or cables.
Once the switch is activated, it must be manually reset by depressing the button underneath the switch.
Technical Specifications
- Switch Type: Single Pole Double Throw (SPDT)
- Actuator: Straight Lever
- Contact Rating:
- 15 A at 125/250/480 VAC
- 0.5 A at 125 VDC
- 0.25 A at 250 VDC
- Mounting: Chassis Mount with elongated holes for easy alignment
- Termination Style: Solder Lug
- Operating Force: Approximately 64 gf
- Operating Temperature Range: -55°C to +85°C
- Ingress Protection: IP64 (dustproof and splash-resistant)
Ensure compatibility with your specific application by reviewing the specifications above.
