Ice Cube Relay - 24V, 16A, 250VAC - Thyssenkrupp LEV
Ice Cube Relay - 24V, 16A, 250VAC - Thyssenkrupp LEV
This item is special-order only and is not regularly stocked. Contact us to confirm pricing and availability before purchasing.
SKU: RLY.LEV.24
Condition: New
Couldn't load pickup availability
Compatible with ThyssenKrupp LEV Units
This high-quality electromagnetic power relay is designed for use in the first generation of ThyssenKrupp LEV elevator units, serving as a reliable replacement for the original relay part number 2124501. It ensures efficient and safe operation of your elevator system by providing dependable switching capabilities.
Key Features:
- Contact Configuration: 2 Pole Double Throw (DPDT)
- Coil Voltage: 24V DC
- Contact Current Rating: 16A at 250V AC
- Coil Resistance: 445Ω
- Mounting Type: Plug-in
- Contact Material: Silver Tin Oxide (AgSnO₂)
This relay is an essential component for maintaining the functionality and safety of your ThyssenKrupp LEV elevator system. Its robust design and reliable performance make it an ideal choice for ensuring uninterrupted operation.
