Elevator Door Safety Sensor Snap‑In Panel Micro Switch

This button switch is used as a door close safety sensor in select ThyssenKrupp LEV and legacy Cheney VPL and Windsor lifts, replacing M10264 & M30782.

This precision snap‑action microswitch provides dependable electrical switching for safety interlocks and door detection in vertical transportation systems. Featuring a panel‑mount design with a pin plunger actuator and quick‑connect terminals, it replaces obsolete part numbers including M10264 and M30782 and fits many legacy lift control panels.

• Double‑pole double‑throw (DPDT) switch configuration for versatile circuit control.
• Rated for up to 10 A at 125 V AC or 277 V AC depending on installation environment.
• Snap‑in panel mount with bullet/plunger actuator ideal for door‑close and safety sensor applications.
• Quick‑connect termination for secure and service‑friendly wiring.
• Durable design with a broad operating temperature range (approx. ‑37 °C to 82 °C).

This switch is widely used as an interlock and safety input component in elevator and lift control systems where trusted performance and electro‑mechanical reliability are essential.

Key Specifications

• Contact configuration: DPDT (Double‑Pole Double‑Throw)
• Electrical rating: 10 A (AC), up to 277 V AC
• Actuator type: Pin/Bullet nose plunger
• Mounting: Snap‑in panel mount
• Termination: Quick‑connect (approx. 4.8 mm)
• Operating temperature: ‑37 °C to 82 °C (approx.)
• Durable snap‑action design with long mechanical life

Elevator technicians and maintenance professionals trust this switch for its compact panel‑mount form, reliable snap‑action performance, and compatibility with established safety sensor circuits. Always ensure installation and testing are performed by qualified personnel and verify suitability in your specific control system.
