Dover 75396 Solenoid Valve Coil - 115/230VAC Dual Voltage

Dover 75396 is a dual-voltage hydraulic elevator solenoid valve coil used on select Dover hydraulic valve assemblies. This replacement coil features a 3/4" inside diameter and supports both 115VAC and 230VAC operation through field wiring configuration mirroring the obsolete valve coil.

Known Specifications

• Solenoid valve coil
• Dual-voltage design
• 115/230 VAC
• 50/60 Hz
• Inside Diameter (I.D.): 3/4"
• Outside Diameter (O.D.): 2-3/4"
• Length: 2-1/8"
• Four-wire configuration
• Hydraulic elevator application

Legacy Part Numbers

• Dover 75396
• Dover 9753965
• Dover 9715575
• Dover 9755895

This coil is commonly referenced as Dover part number 75396 and has been associated with several legacy Dover hydraulic valve configurations.

Some field installations have been observed with a Dover 75397 marking on a visually similar dual-voltage coil. While available specifications suggest similarities between the 75396 and 75397 coils, interchangeability has not been confirmed. Always verify dimensions, voltage requirements, and valve application before ordering.

Need Help Identifying Your Coil?

Send us a photo of the coil label and valve assembly and we'll help verify compatibility before purchase.

Professional Installation Required

This product is intended for use by qualified elevator service personnel familiar with hydraulic elevator systems and electrical troubleshooting procedures. Verify all specifications, dimensions, and application requirements before installation. If you need assistance identifying the correct replacement coil, contact us with photos and available part numbers prior to ordering.
