Dormeyer Laminated Brake Solenoid – 120 VAC - Waupaca Dumbwaiters

Designed for durability and reliable use in older Waupaca dumb waiters as a direct replacement for legacy OEM #A0‑001654. Laminated steel construction ensures consistent pull performance up to 1 in of stroke.

Constructed from robust laminated steel, this continuous-duty solenoid features a corrosion-resistant frame and plunger. It’s engineered for dependable pull-force operation up to 1 inch of stroke. Coil operates at 120 VAC with solder-lug terminals, offering smooth motion with a gravity value of approximately 5.9 oz. Fits standard mounting patterns and provides clear compatibility for Waupaca setups.

• Continuous-duty laminated steel construction
• Stroke range from 1/8 in to 1 in
• Pull‑force range approximately 88–168 oz
• Coil voltage: 120 VAC, seated power ~19 W; seated current ~0.48 A
• Coil resistance ~14.9 Ω
• Maximum stroke current ~6.5 A
• Approximate dimensions: 2 1/2 in (L) × 2 1/16 in (W) × 2 1/16 in (D)
• Gravity value (force acting under gravity): ~5.92 oz
• Mounting hole spacing: 2 × 1‑5/8 in centers

Reliable and rugged, this solenoid delivers consistent pull performance suitable for maintaining safe braking operations in Waupaca dumbwaiter systems.
