Door Micro Switch - Cheney

Compatible with Cheney wheelchair lifts manufactured prior to September 1986, including early VPL (Vertical Platform Lift) models.

Durable mini snap action switch ensures precise door presence detection in legacy Cheney VPL wheelchair lifts.

This subminiature micro switch is designed for high-cycle applications like door presence sensing in older vertical platform lifts. Its roller lever actuator delivers fast, repeatable switching, while the compact form factor fits tight control enclosures. This SPDT microswitch offers reliable performance in low-voltage DC systems.

Specifications:

• Actuator Type: Roller Lever
• Contact Configuration: SPDT (Single Pole Double Throw)
• Switch Function: ON - (OFF), OFF - (ON)
• Contact Rating: 5 A @ 250 VAC; 3 A @ 250 VAC (Inductive)
• Voltage Rating: 250 VAC; 30 VDC
• Operating Force: 1.95 N (7 ozf)
• Release Force: 0.56 N
• Termination Style: Quick Connect
• Operating Temperature Range: -54°C to +121°C
• Mechanical Durability: 10 million cycles
• Case Material: Phenolic
• Contact Material: Gold Plated Silver
• IP Rating: IP40
• Body Dimensions: 19.8 x 6.4 x 10 mm

Ensure proper alignment and secure mounting to maintain consistent operation. Verify compatibility with existing wiring and terminal types before installation.
