Control Power Transformer for Matot Dumbwaiter 100 Series – 240/480V to 120V, 300VA, Single Phase

T300D1 Control transformer designed for Matot dumbwaiter model 100 systems, stepping down 240/480V to 120V with a 300VA power rating.

This industrial-grade control power transformer is a direct replacement for many Matot dumb waiter systems, especially those in the model 100 series. It steps down high-voltage input—either 240 V or 480 V AC—to a standard 120 V output suitable for control circuits. Featuring a durable open-style frame and screw clamp terminals, this unit is engineered for panel mounting within electrical cabinets. Its 300 VA capacity and 50/60 Hz operation make it a dependable fit for elevator support systems requiring steady and isolated control voltage.

• Input Voltage: 240 × 480 VAC
• Output Voltage: 120 VAC (also supports 110/115 V)
• Power Rating: 300 VA
• Frequency: 50/60 Hz
• Phase: Single-phase
• Mounting Type: Panel mount
• Enclosure Type: Open frame
• Terminal Type: Screw clamp
• Insulation Class: 130 °C
• Temperature Rise: 80 °C
• Approximate Dimensions: 4.5″ W × 4.74″ D × 3.84″ H
• Certifications: UL, cUL, CSA, CE

Always ensure that replacement electrical components are installed by qualified personnel following all applicable codes. Using the correct transformer helps maintain consistent performance and long-term reliability in your lift system.
