Cheney Ball Screw B/N Wiper - Ball Nut
Cheney Ball Screw B/N Wiper - Ball Nut
This item is Preferred Access only and is not regularly stocked. Contact us to confirm eligibility, pricing, and availability before purchasing.
LPP Part Number: BN.CH.100
Condition: New
Couldn't load pickup availability
Compatible with: Cheney VPLs including many Handi-Lift II & Cheney Series 2000 VPLs
High-performance replacement ball nut for Cheney wheelchair lifts, ideal for restoring smooth and reliable lift motion.
This precision-engineered B/N wiper is commonly used in Cheney Handi-Lift II and Series 2000 wheelchair lift models. Designed to match the original fit and function, it ensures dependable lift performance and long-lasting durability.
Specifications:
- Nominal Diameter: 1"
- Lead (Travel per Turn): 0.25"
- Thread Size: 1.563-18 UNEF
- Number of Circuits: 2 with Load Lock
- Dynamic Load Capacity: 1,612 lbs
- Static Load Capacity: 13,913 lbs
- Torque to Raise 1 lb: 0.71 oz-in
- Nut Weight: 0.81 lbs
Note: If out of stock, lead time is approximately 4 weeks due to manufacturer availability. Please plan ahead to avoid service delays.
