CEMCO Elevator Guide Rail Roller - Upper and Lower

Yellow polyurethane elevator guide rail rollers with 6306Z bearing, available in Top (148mm OD) and Bottom (197mm OD) sizes for compatible CEMCO lifts.

Designed for use in Cemco cantilever-style hydraulic elevators, these guide rail rollers ensure smooth, quiet, and reliable vertical travel. Each roller features a durable yellow polyurethane tread bonded to a black core, with a factory-installed 6306Z bearing at the center. The upper roller has a compact profile for top guide assemblies, while the larger lower roller supports bottom track alignment. Sold individually, these rollers are ideal replacements where precise fit and performance are required.

• Upper Roller Diameter: 148.1mm (5.82")
• Lower Roller Diameter: 197mm (7.76")
• Width (Both Sizes): 35mm (1.38")
• Bore Size: 30mm (1.18")
• Bearing Type: 6306Z sealed bearing (pre-installed)
• Outer Color: Yellow tread with black core
• Application: Common on Cemco roped, holeless, and cantilever hydraulic elevators

Always ensure parts are installed by qualified personnel in accordance with your lift system's service requirements. Using high-quality, properly fitted rollers helps maintain optimal performance and safety over time.
