Call Station Pushbutton for RAM Trus-T-Lift TTL750

Designed for use in compatible vertical platform lift (VPL) call stations, this non-illuminated pushbutton provides momentary contact operation, returning to its normal position when released. Its durable plastic bezel and screw-terminal connections make it suitable for accessibility lift control applications.

This replacement call station button is intended for select RAM Trus-T-Lift TTL750 wheelchair lifts requiring a black, momentary pushbutton with a single normally open (NO) contact. Compatibility depends on the electrical configuration and call station assembly installed on the lift.

Specifications:

• Manufacturer: ABB
• Component Type: Call Station Pushbutton
• Application: Select RAM Trus-T-Lift TTL750 Vertical Platform Lifts
• Button Color: Black
• Bezel Material: Plastic
• Operation: Momentary
• Illumination: Non-Illuminated
• Contact Configuration: 1 Normally Open (NO) or 2 Normally Open (NO)
• Dimensions: 30 mm W × 30 mm H × 60 mm D
• Weight: 0.018 kg
• Rated Operational Voltage: 300V Maximum
• Rated Insulation Voltage: 300V
• Rated Impulse Withstand Voltage: 6 kV
• Rated Frequency: 50/60 Hz
• AC-15 Rating: 2A at 240V
• DC-13 Rating: 0.3A at 24V; 0.2A at 125V
• Connection Type: Screw Clamp Terminals
• Wire Capacity: 22–14 AWG (UL/CSA)
• Tightening Torque: 0.8 N·m
• Wire Stripping Length: 6 mm
• Operating Temperature: -25°C to +70°C
• Storage Temperature: -40°C to +85°C
• Front Protection Rating: IP66, IP67, IP69K
• Terminal Protection Rating: IP20
• NEMA Enclosure Types: 1, 12, 13, 3R, 4, 4X
• Mechanical Durability: 500,000 Operations

Proper installation of replacement lift control components is essential for maintaining reliable equipment operation. All electrical components should be installed by qualified lift service personnel in accordance with applicable safety standards and equipment requirements.
