3″ x 1.5″ Rubber Replacement Roller Wheel for Platform Lift & Elevator

Replacement 3″ x 1.5″ phenolic (rubber‑feel) roller wheel for Savaria and REI lifts. 500 lb capacity, ¾″ bore, 1-5/8″ hub length.

This premium replacement roller wheel is designed to match many platform lift (VPL) applications such as Savaria Telecab and V‑1504 models (replaces #MA2AB / commonly marked “Jalson 3×1.5”), and many Residential Elevator Inc. (REI) elevators (replaces #REW‑001).
Although the wheel surface feels similar to rubber, it is actually constructed of durable phenolic resin for superior longevity, quiet operation and floor protection. The roller features a 3″ diameter, 1.5″ tread width, ¾″ bearing bore, and a hub length of 1.625″. Rated to support up to 500 lb each, with 90 Shore D hardness and resistance to chemical, steam and impact exposure.

To complete your installation:

• For Savaria replacements, retain the original roller spacer (or source a matching spacer locally)
• For REI replacements, retain the original washers, bolt and nut (or replace with equivalent hardware from a local hardware store)

  This listing includes only the roller wheel itself — hardware, spacer, washers and bolts are not included.

Specifications:

• Diameter: 3″
• Tread width: 1.5″
• Bearing inner diameter: 0.750″ (¾″)
• Bore less bearing: 1.1875″ (1 3/16″)
• Hub length: 1.625″ (1 5/8″)
• Load capacity: 500 lb each
• Hardness: 90 (±5) Shore D
• Material: Phenolic resin
• Temperature rating: –45 °F to +250 °F
• Tread profile: Crowned (for smooth tracking)

This high‑performance roller wheel is built to meet demanding platform lift environments. For safe, reliable operation, we recommend installation by qualified personnel using proper mounting hardware and alignment.
