1 HP 24 VDC Permanent Magnet Motor — Replacement for NWOV VPL Lifts

1 HP 24 VDC reversible lift motor for legacy Wheel‑O‑Vator and other wheelchair lifts, direct replacement for W4BB1604, 4BC‑01605, 4BB1604, W4BC1605.

This 1 HP 24 VDC motor is engineered as a drop‑in replacement for the legacy National Wheel‑O‑Vator (NWOV) and similar vertical platform lifts (VPLs) that originally used W4BB1604, 4BC‑01605, 4BB1604, or W4BC1605 motors. It delivers high torque, reversible (CW/CCW) operation, and fits within the mechanical envelope of the original design, enabling retrofit upgrades without major structural changes.

Key features include permanent‑magnet construction for high efficiency, robust shaft and bearing design, and compatibility with standard 24 V lift control systems. This motor is ideal for platform lifts using 24 V battery or DC systems where a reliable, high‑performance drive is required.

Specifications:

• Horsepower: 1 HP
• Voltage: 24 VDC (nominal)
• Direction: Bidirectional (CW / CCW)
• Full Load Current: ~ 80 A
• Speed (no load / rated): ~ 1,800 RPM
• Shaft: 5/8″ diameter, 2″ length
• Motor length (overall): 11.75″
• Mounting frame: 56C, PM (permanent magnet) style
• Insulation class: F
• Duty class: Intermittent (S2)
• Bearing arrangement: double ball bearing (drive end)

This motor is intended for professional installations. All wiring and control integrations must be performed by qualified technicians to preserve safety and performance.
